Product Description
Detail display
1.The motor ofthe high-pressure blower is rated ip55 for protection and class Finsulation level heat resistant up to 155"c, which extends its service life.
2.100% oil-free and water-free compression, air clean and sanitary.
3. All products adopt dual-frequency 50Hz/60Hz, wide votage desien,covering and meeting the voltage levels worldwide, enhancing stability.
4.The mpeler and pump body are both castby high qualtyaluminumaloy molds,which improves the durabity,stabily,and ruggednes ofthe product.This ensures a highmprecision manufac turing process and an attractive appearance.
5.Germany and Japan import high-precision CNc machine tools for procesing,and strict performance testing and experiments areconducted to ensure excelentproduc performance.
6. Good sealing performance, low noise, maintenance-free use, low mechanical wear, and long service life.
The impeler ofthe airine pumpis irectlyinstaled onthe motor rotor,which is completely non-contact compression.Duetothe instalation ofthe shalt outidethe compression chamber, even under the maximum pressure diference, it can ensure the maximum working reliability of the machinery.
The gas is sucked in by the air inlet 1,but after it enters the side channe!2, the rotatingimpeller3 gives the gas a velocityin the direction ofrotation, and the centrifugalforceon the blade causes the gas to be connected outward and the pressure to increase.
As the rotation progresses, the kinetic energy ofthe gasincreases,furtherincreasingthe gas pressure alongthe side channe. As the side channel narows at the outlet,gas issqueezed out of the blades and discharged from the pump body through the air outlet 4.
|
Model |
Single |
Freguency |
Output |
Voltage |
Current |
Max Airflow |
Rated Vacuum |
Rated Compress |
Npises |
Weight |
|
Double |
HZ |
KW |
V |
A |
m3/h |
mbar |
mbar |
dB(A) |
kg |
|
|
4JB210-H16 |
Single |
50 |
0.55 |
200-240△/345-415Y |
2.8△/1.6Y |
47 |
-230 |
290 |
57 |
16 |
|
60 |
0.63 |
220-275△/380-480Y |
3△/1.7Y |
57 |
-270 |
320 |
62 |
|||
|
4JB310-H16 |
Single |
50 |
0.55 |
200-240△/345-415Y |
2.8△/1.6Y |
66 |
-250 |
250 |
57 |
16 |
|
60 |
0.63 |
220-275△/380-480Y |
3△/1.7Y |
80 |
-260 |
250 |
62 |
|||
|
4JB310-H26 |
Single |
50 |
0.81 |
200-240△/345-415Y |
4△/2.3Y |
66 |
-280 |
350 |
57 |
17 |
|
60 |
0.94 |
220-275△/380-480Y |
4△/2.3Y |
80 |
-340 |
360 |
62 |
|||
|
4JB410-H16 |
Single |
50 |
1.1 |
200-240△/345-415Y |
5.4△/3.1Y |
87 |
-300 |
380 |
58 |
23 |
|
60 |
1.3 |
220-275△/380-480Y |
5.4△/3.1Y |
105 |
-340 |
370 |
62 |
|||
|
4JB510-H16 |
Single |
50 |
1.5 |
200-240△/345-415Y |
7.5△/4.3Y |
120 |
-310 |
360 |
64 |
26 |
|
60 |
1.75 |
220-275△/380-480Y |
7.6△/4.4Y |
145 |
-340 |
320 |
68 |
|||
|
4JB510-H26 |
Single |
50 |
2.2 |
200-240△/345-415Y |
11.4△/6.6Y |
120 |
-310 |
470 |
64 |
29 |
|
60 |
2.55 |
220-275△/380-480Y |
11.2△/6.5Y |
145 |
-360 |
480 |
68 |
|||
|
4JB610-H16 |
Single |
50 |
2.2 |
200-240△/345-415Y |
11.4△/6.6Y |
165 |
-340 |
360 |
65 |
32 |
|
60 |
2.55 |
220-275△/380-480Y |
11.2△/6.5Y |
195 |
-360 |
315 |
71 |
|||
|
4JB610-H36 |
Single |
50 |
3.3 |
200-240△/345-415Y |
13△/7.5Y |
165 |
-340 |
480 |
65 |
35 |
|
60 |
3.8 |
220-275△/380-480Y |
14.2△/8.2Y |
195 |
-380 |
530 |
71 |
|
Model |
Single |
Frequency |
Output |
Voltage |
Current |
Max Airflow |
Rated Vacuum |
Rated Compress |
Noises |
Weight |
|
Double |
HZ |
KW |
V |
A |
m3h |
mbar |
mbar |
dB(A) |
kg |
|
|
4JB220-H26 |
Double |
50 |
0.81 |
200-240△/345-415Y |
4△/2.3Y |
47 |
-370 |
490 |
58 |
24 |
|
60 |
0.94 |
220-275△/380-480Y |
4△/2.3Y |
60 |
-440 |
480 |
62 |
|||
|
4JB220-H56 |
Double |
50 |
1.5 |
200-240△/345-415Y |
7.5△/4.3Y |
47 |
-370 |
650 |
58 |
28 |
|
60 |
1.75 |
220-275△/380-480Y |
7.6△/4.4Y |
60 |
-500 |
740 |
62 |
|||
|
4JB320-H46 |
Double |
50 |
1.1 |
200-240△/345-415Y |
5.4△/3.1Y |
65 |
-400 |
480 |
59 |
29 |
|
60 |
1.3 |
220-275△/380-480Y |
5.4△/3.1Y |
76 |
-480 |
480 |
63 |
|||
|
4JB320-H56 |
Double |
50 |
1.5 |
200-240△/345-415Y |
7.5△/4.3Y |
65 |
-440 |
540 |
59 |
30 |
|
60 |
1.75 |
220-275△/380-480Y |
7.5△/4.4Y |
76 |
-560 |
600 |
63 |
|||
|
4JB420-H26 |
Double |
50 |
1.5 |
200-240△/345-415Y |
7.5△/4.3Y |
87 |
-480 |
450 |
61 |
33 |
|
60 |
1.75 |
220-275△/380-480Y |
7.6△/4.4Y |
105 |
-430 |
410 |
66 |
|||
|
4JB420-H56 |
Double |
50 |
3.3 |
200-240△/345-415Y |
13△/7.5Y |
87 |
-500 |
750 |
61 |
39 |
|
60 |
3.8 |
220-275△/380-480Y |
13.8△/8Y |
105 |
-510 |
850 |
66 |
|||
|
4JB520-H26 |
Double |
50 |
2.2 |
200-240△/345-415Y |
11.4△/6.6Y |
120 |
-470 |
460 |
64 |
40 |
|
60 |
2.55 |
220-275△/380-480Y |
11.2△/6.5Y |
145 |
-500 |
450 |
70 |
|||
|
4JB520-H77 |
Double |
50 |
4 |
345-415△ |
9△ |
120 |
-500 |
820 |
65 |
51 |
|
60 |
4.6 |
380-480△ |
9.5△ |
145 |
-530 |
810 |
71 |
|||
|
4JB620-H36 |
Double |
50 |
3.3 |
200-240△/345-415Y |
13△/7.5Y |
165 |
-460 |
500 |
67 |
48 |
|
60 |
3.8 |
220-275△/380-480Y |
14.2△/8.2Y |
195 |
-480 |
420 |
71 |
|||
|
4JB620-H57 |
Double |
50 |
5.5 |
345-415△ |
12.5△ |
165 |
-460 |
740 |
68 |
65 |
|
60 |
6.3 |
380-480△ |
12△ |
195 |
-480 |
840 |
72 |
|||
|
4JB650-H67 |
Three |
50 |
7.5 |
345-415△ |
16△ |
170 |
-730 |
1040 |
72 |
86 |
|
60 |
8.6 |
380-480△ |
16△ |
200 |
-700 |
1040 |
76 |
